Краткое содержание страницы № 1
APPLY SERIAL NUMBER LABEL FROM CARTON
Serial No. XXXXXX000000
MODEL NO.
ASSEMBLY AND OPERATING INSTRUCTIONS
MIRAGE 730
OUTDOOR STAINLESS STEEL GAS GRILL
DANGER
NOTICE TO INSTALLER:
IF YOU SMELL GAS:
• Shut off gas to the appliance.
LEAVE THESE INSTRUCTIONS
• Extinguish any open flame.
WITH THE GRILL OWNER FOR
• Open lid.
FUTURE REFERENCE
• If odor continues, keep away from the
appliance and immediately call your
gas supplier or your fire department
DO NOT TRY TO LIGHT THIS APPLIANCE WITHOUT
The familiarity with propane most often is tied to grilling, but it does so much more than that. Propane is used for heating, cooking, materials handling, on and off-road vehicles, back up power supply, and a number of industrial processes. Propane is used to supply entire communities when. Yale propane forklift manual: online pdf manual free on 1n.haberokur.site. Parts Town has the largest in-stock inventory of foodservice replacement parts from manufacturers you know and trust. Same day shipping until 9pm ET. Sansui Serial Numbers Page 1 of 132 - AudioKarma Serial Number Sansui Serial Numbers Date of Manufacture Wednesday. PROPANE TANK TOP HEATER MODEL. Domestic Propane Tanks. Manchester Tank's Horizontal Domestic Propane Tanks are Made with Pride, Made in the U.S.A. Propane Tanks & Cylinders for LP Gas Systems. OUR STANDARD IS THEIR UPGRADE. Manchester Tank's 200 lb. Tanks and cylinders are fully equipped with RegO Products' Multi-Bonnet® assembly and Presto-Tap.
Краткое содержание страницы № 2
THANK YOU FOR CHOOSING NAPOLEON NAPOLEON products are designed with superior components and materials, and are assembled by trained craftsmen who take great pride in their work. The burner and valve assembly are leak tested and test-fired at a quality test station. This grill has been thoroughly inspected by a qualified technician before packaging and shipping to ensure that you, the customer, receive the quality product you expect from NAPOLEON. We at Napoleon are dedicated to you, “our valu
Краткое содержание страницы № 3
SAFETY PRECAUTIONS WARNING WARNING Do not store or use gasoline or other Failure to follow these instructions could flammable liquids or vapor in the vicinity of result in property damage, personal injury or this or any other appliance. An L.P. cylinder death. Read and follow all warnings and not connected for use must not be stored in instructions in this manual prior to operating the vicinity of this or any other appliance. grill. Keep area clear and free from combustible materials. SAFE OPE
Краткое содержание страницы № 4
CAUTION CYLINDER SPECIFICATIONS/GAS HOOK UP This gas barbecue is certified under Canadian and American national standards, CAN/CSA-1.6-2005 and ANSI Z21.58 -2005 respectively for outdoor gas grills and should be installed to conform with local codes. In absence of local codes, install to the current CAN/CGA-B149.1 Propane Installation Code in Canada or to the National Fuel Gas Code, NFPA54/ANSI Z223.1 in the United States. If a rotisserie motor is used, it must be electrically grounded in accor
Краткое содержание страницы № 5
LIGHTING INSTRUCTIONS OPEN LID. LEFT BURNER ENSURING BURNER CONTROLS ARE IN THE OFF POSITION, TURN ON THE GAS SUPPLY VALVE. REAR LEFTCENTER CENTER RIGHTCENTER SIDE INFRARED BURNER BURNER BURNER BURNER BURNER BURNER REAR BURNER LIGHTING SIDE BURNER LIGHTING MAIN BURNER LIGHTING (ROTISSERIE BURNER) 1. PUSH AND TURN ANY MAIN 1. OPEN SIDE BURNER 1. REMOVE THE BURNER KNOB SLOWLY TO COVER. WARMING RACK THE ’HI’ POSTION. THIS ACTION WILL IGNITE THE PILOT FLAME WHICH WILL IN TURN LIGHT THE SELECTED
Краткое содержание страницы № 6
OPERATING THE GRILL BURN - IN PROCEDURE When lit for the first time, the gas grill will emit a slight odour. This is a normal temporary condition caused by the 'burn-in' of internal paints and lubricants used in the manufacturing process and will not occur again. Simply run the main burners on high for approximately ½ hour with the lid closed. MAIN BURNER USE: When searing foods, preheating is recommended by operating all main burners in the high position with the lid closed for approximately 15
Краткое содержание страницы № 7
INFRARED HEAT Most people don’t realize that the heat source that we are most familiar with, namely the sun warms the earth using mainly infrared energy. Infrared energy is a form of electro-magnetic energy that has a wavelength just greater than the red end of the visible light spectrum, but less than that of radio waves. This energy was discovered in 1800 by Sir William Herschel who, dispersed sunlight into its component colours using a prism. He showed that most of the heat in the beam fel
Краткое содержание страницы № 8
MAINTENANCE/CLEANING INSTRUCTIONS It is recommended that this gas grill be thoroughly inspected and serviced annually by a qualified service person. Note: Stainless steel tends to oxidize or stain in the presence of chlorides and sulfides, particularly in coastal areas and other harsh environments, such as the warm, high humidity atmosphere around pools and hot tubs. These stains may be perceived as rust, but can be easily removed and prevented. To ensure stain prevention, wash all stainless ste
Краткое содержание страницы № 9
MAINTENANCE/CLEANING INSTRUCTIONS HOSE - Check for abrasion, melting, cuts and cracks. If any of these conditions exist, do not use gas grill. Have part replaced by your Napoleon Gas Grill dealer, or qualified gas installer. CLEANING THE OUTSIDE OF THE GAS GRILL - Do not use abrasive cleaners to clean any painted, porcelain or stainless steel parts. Porcelain enamel components must be handled with additional care. The baked on enamel finish is glass like, and will chip if struck. Touch-up e
Краткое содержание страницы № 10
TROUBLESHOOTING Problem Possible Causes Solution Low heat / Low flame when For propane - improper lighting Ensure lighting procedure is followed carefully. All gas grill valve turned to high. procedure. valves must be in the off position when the tank valve is turned on. Turn tank on slowly to allow pressure to equalize. See lighting instructions. For natural gas - undersized Pipe must be sized according to installation code. supply line. For both gases - improper Pre-heat grill with all main
Краткое содержание страницы № 11
ORDERING REPLACEMENT PARTS WARRANTY INFORMATION KEEP YOUR RECEIPT MODEL: AS PROOF OF PURCHASE TO DATE OF PURCHASE: VALIDATE YOUR WARRANTY. SERIAL NUMBER: (record information here for easy reference) Before contacting the customer care department, check the NAC web site for more extensive cleaning, maintenance, troubleshooting and part replacement instructions at www.napoleongrills.com. Contact the factory directly for replacement parts and warranty claims. The customer care department is avail
Propane Tank Serial Number Lookup Online
Краткое содержание страницы № 12
7/16 3/8 ASSEMBLY INSTRUCTIONS CAUTION: During unpacking and assembly it is recommended that you wear work gloves and safety glasses for your protection. Although we make every effort to make the assembly process as problem free and safe as possible, it is characteristic of fabricated steel parts that the edges and corners may be sharp and can cause cuts if handled incorrectly during assembly. GETTING STARTED 1. Remove all cart panels, hardware, and grill head from carton. Raise lid and remov
Краткое содержание страницы № 13
3/8 7/16 2 x N430-0002 MAGNET CATCH 1 Magnet Installation Snap magnets into slots in front of bottom shelf. 16 X 16 X N570-0073 (1/4-20 X 3/8”) N450-0027 (1/4-20) Caster Installation 2 Attach (4) casters using (4) 1/4 - 20 X 3/8” screws and (4) 1/4-20 lock nuts for each caster. Attach brackets under front casters as illustrated below. Tighten securely. non revolving caster- left side 13
Краткое содержание страницы № 14
3/8 PROPANE ONLY 3 Propane Tank Ring Installation Insert propane tank ring into slots in bottom shelf as shown. Fold tabs over to secure in place. 4 X N570-0080 (#14 X 1/2') Left and Right Cart Panel Installation 4 Install end cart panels ensuring slots in panel are to the top, rest panel on bottom shelf and line up holes. Fasten using (4) #14 x 1/2” screws. 14
Краткое содержание страницы № 15
Data Plate On Propane Tank
3/8 6 X N570-0080 (#14 X 1/2') 5 Rear Cart Panel Installation Fit rear cart panel between the two end panels, ensure large hole in panel is to the bottom right hand corner as illustrated. Fasten using (6) #14 x 1/2” screws, three on each side. 6 Condiment Basket / Propane Tank Mount Installation Rotate basket slightly to allow wire to enter the holes in the side panel. Push through and upwards, rotating to allow the bend in the wire to pass through the holes. Lay basket flat against the side
Краткое содержание страницы № 16
3/8 4 X N570-0080 (#14 X 1/2') 7 Drawer / Housing Installation Place complete drawer housing assembly onto bottom shelf lining up holes in housing with holes in bottom shelf. Fasten using (4) #14 X 1/2” screws. 16
Propane Tank Serial Number Lookup Vin
Краткое содержание страницы № 17
3/8 3/8 6 X N570-0080 (#14 X 1/2') Front Cabinet Support Installation 8 Fasten top rail assembly to the front of side panels and top of the drawer housing assembly using (6) #14 x 1/2” screws. For ease of installation start all screws before tightening completely. 2 X PROPANE ONLY N570-0080 (#14 X 1/2') 9 Propane Tank Heat Shield Installation Attach propane tank heat shield above propane tank ring. Attach one end under lip of back panel and other end to underside of front cabinet support. 17
Краткое содержание страницы № 18
3/8 6 x N570-0073 (1/4-20 x 3/8”) Grill Head Installation 10 PROPANE ONLY - To avoid assembly difficulties, prior to mounting the grill head, remove zip tie holding regulator up under control panel. This was installed at the factory to protect the regulator hose during shipping and is no longer required. (Take care when removing the tie not to damage the hose). Ensure the regulator drops into the small opening, between the tank heat shield and the right side of the cabinet. Lift grill
Краткое содержание страницы № 19
3/8 3/8 10 x N570-0073 (1/4-20 x 3/8') Assembling End Caps to Side Shelf / Side Burner 11 Peel protective coating from side shelf / side burner. Attach corresponding end cap as shown using (5) 1/4-20 x 3/8” screws. Bend Tabs on front of shelf up with a flat head screw driver, insert screw through tab and into end cap. 4 X 4 X N735-0001 (1 1/16” insulated washer) N570-0082 (1/4-20 x 5/8') 12 Side Shelf Installation Insert (4) 1/4-20 x 5/8” screws through washers into threaded holes in side of
Краткое содержание страницы № 20
Propane Tank Serial Number Lookup Service
3/8 1 X 4 X 4 X N160-0016 N735-0001 (1 1/16” insulated washer) N570-0082 (1/4-20 x 5/8') 13 Side Burner Installation Insert (4)1/4-20 x 5/8” screws through washers into threaded holes in side of base. Do not tighten all the way. Slide assembled side burner over screw heads and finish tightening. Fit orifice into burner tube and secure with hose retainer clip sup- plied. Attach wire from manifold to side burner electrode. 20
